Description
xProfessional-Grade Porsche Diagnostics & Coding Tool with PIWIS II
The VXDIAG VCX PLUS for Porsche is a powerful OEM-level diagnostic and programming interface designed for 2005–2016 Porsche vehicles using PIWIS II software. Supporting DoIP Ethernet, J2534, and multiple OEM protocols, it’s the ideal tool for workshops, advanced technicians, and Porsche enthusiasts.
🔧 Key Functions & Highlights:
-
✅ All-System Diagnostics
-
Access all ECUs: Read/clear fault codes, live data, ECU info, freeze frame, and active tests.
-
-
🚀 ECU Programming & Online Coding
-
Perform ECU upgrades, coding changes, component adaptation, and online hidden function unlocking.
-
-
🔒 Hidden Feature Activation
-
Unlock advanced functions: auto handbrake release, rain-activated sunroof closure, lane change alerts, CIC menu, and more.
-
-
🧰 Advanced Service Functions
-
Includes oil reset, throttle relearn, EPB, DPF regen, ABS bleeding, SAS calibration, headlight adjustment, and others.
-
-
📊 Circuit Diagram & Parts Lookup
-
Access wiring diagrams and parts info directly from software for accurate diagnostics and repair guidance.
-
-
🌐 Multi-Protocol Compliance
-
Fully supports SAE J2534-1/2, ISO-22900 (D-PDU), ISO-13400 (DoIP), and RP-1210A/B/C for OEM compatibility.
-
-
📶 Flexible Connectivity
-
Connect via USB, LAN, or WiFi. Supports remote diagnosis via serial number for newer models.
-
-
🔄 Free Lifetime Firmware/License Updates
-
Easily update via VX Manager to ensure long-term compatibility and performance.
-
📦 What’s in the Box:
-
1× VXDIAG VCX PLUS Main Unit (for Porsche PW2)
-
1× OBD Main Cable
-
1× USB Cable
-
1× LAN Cable
⚠️ Important Notes:
-
💻 Software Not Included: Supports PIWIS II software, but users must obtain software and online account independently.
-
🛠 PC Requirements: Windows PC with ≥1GB RAM, 40GB+ storage, 1024×768 resolution, USB or LAN interface.
-
🧊 Operating Temp: –20°C to 70°C | Warranty: 1 Year
1. PC Requirement:
| Component | Specification |
|---|---|
| Processor | Pentium 4 / 1.6GHz+ |
| Memory | 1G Bytes or more |
| Hard Disk | 40G or more |
| Display | Resolution 1024x768 or higher |
| Network Interfaces | LAN 10 / 100M or 802.11b/g |
| Communication Interface | USB2.0 or USB3.0 |
2. Specification:
| Component | Specification |
|---|---|
| RAM | 32bit 180MHz ARM |
| FLASH | 1MByte FLASH |
| Diagnostic Port | 24PIN, self-determination design |
| LED | 4 LED indicator lights (indicate power and status) |
| Power | DC 9V-36V |
| Consumption | 3W |
| Working Temperature | -20°C ~ 70°C |
| Storage Temperature | -40°C ~ 85°C |
| Warranty | One Year |
